200m VGA Receiver with Adjustment Knob for Definition and Brightness
Features:
1. Can combine used with any specification of our company’s transmitter,to extend the
VGA video and audio signals to 200 meters long,can adjust the definition and brightness
according to the distance.
2. Support hot-swapping,can works stable all year round.
3. Broadcast-grade 600MHz video bandwidth, balanced drive transmission, excellent
anti-jamming performance.
4. Built-in industrial-grade lightning protection and surge protection circuit to improve product performance and extend product life.
5. H/V Sync digital shaping circuit to enhance the stability of the display screen, enhance the compatibility of the product.
Specifications
Receiver dimension—————————————————————————95*97*28mm
Video signal bandwidth————————————————————————600MHz@-3dB
Video signal gain————————————————————————6dB@ full bandwidth
Video signal peak————————————————————————0-0.7Vp-p
Best resolution—————————————————————————1024*768@60Hz - 1920*1200@60Hz
UTP signal peak———————————————————————2.0-3.5Vp-p
VGA port——————————————————————————HD15 pin female
Audio signal bandwidth————————————————————————10Hz-20KHz
Audio signal output impedance——————————————————————600Ω
Audio port——————————————————————————3.5mm male plug
Power supply——————————————————————————DC9-12V/1000mA
Protection grade——————————————————————————Industrial lightning / surge protection
Operation temperature——————————————————————————-25℃-55℃
